Data Center Lift Attachments
Fact: Most of our attachments were designed based on customer feedback. We listen, and we respond. Each attachment is shown below with a description of its function.
LE-serien™ Løftutvidelser
Pakk enkelt servere fra esker
The ServerLIFT LE-500X™ and LE-1000X™ Lift Extensions are used to safely lift and remove servers, switches, UPS devices, and other rack-mounted equipment out of boxes and off of pallets without destroying the packaging or straining your back. These critical tools free operators from ever having to manually unpack boxes or lift equipment ever again.
Compatible Lifts
PL-500X™ Utvidelse av plattformen
IT-utstyrshåndtering ned til gulvet
PL-500X™ Platform Extension brings the reach of the ServerLIFT® machine down to the floor, so that it can safely and precisely handle equipment at bottom rack positions for near-ground installs. Extend your reach beyond and below the ServerLIFT® machine frame, enabling you to perform assisted moves in even the most challenging of spaces.
Compatible Lifts
GT-1000x™ Glide Platform
Enkel, friksjonsfri serverbevegelse
The GT-1000X™ Glide Platform helps you load and unload heavy servers with ease. The integrated rollers reduce friction for effortless gliding, and can also be locked out with the built-in brake for safely securing the server in place during transport. Slide servers and switches on or off the ServerLIFT® platform for a no-stress server move…. every time.
Compatible Lifts
RS-500X™ J-Rail Assist
Vinkle inn eller ut av spalte skinner
tThe RS-500X™ J-Rail Assist supports server equipment while giving the operator control over the angle of the server at all points of installation or removal from the rails. Capable of attaching to the ServerLIFT® platform, the RS-500X™ J-Rail Assist can be used to easily tilt servers into slotted guard rails or keep them level for non-slotted, bolt-in installs.
Compatible Lifts
RL-500™ Plattform Riser
Nå toppen av ethvert rack sikkert
The RL-500™ Platform Riser ensures that server installs are seamless and safe for all data center specifications, including environments with overhead obstructions. Along with optimum server support for top-of-the-rack installs, the RL-500™ Platform Riser raises the working height of the platform itself, expanding the capability of the ServerLIFT® machine to over 58U high.
Compatible Lifts
VMH-500X™ Vertical Module Handler
Secure Support for Vertical Chassis Components
The VMH-500X™ Vertical Module Handler is specifically designed to support vertical modules during installation or removal, ensuring stability and ease of handling. Compatible with large chassis systems like the Arista 7812 and 7816L Fabric Modules, it works seamlessly with both side-loading and front-loading ServerLIFT® units. This accessory keeps vertical components securely in position, improving safety and precision during data center operations.
Compatible Lifts
GR-500X™ Multi-Axis Roller Table
Smooth, Precise Loading
The GR-500X™ Multi-Axis Roller Table is designed for versatile equipment handling, accommodating both side and front loading when used with front-loading lifts. Its integrated ball bearings allow for smooth, low-friction movement, making it easy to position heavy equipment precisely. Once in place, a convenient brake mechanism securely holds the load off the rollers to ensure stability during installation or removal.
Compatible Lifts
WS-1X™ 17 "Bred hylle
Bygget for å støtte brede servere
The WS-1X™ Wide Shelf is a 17″ (43.2 cm) wide plate attachment that provides additional shelf surface area to fully support servers across their entire width. Designed for uncrating and installing the NVIDIA DGX-2 and the NVIDIA DGX A100, it supports up to 500 lbs (227 kg) at the center and 300 lbs (136 kg) at the extended side edge. The WS-1X™ is compatible with the SL-350X®, SL-500X®, and the SL-1000X® ServerLIFT® data center lifts.
Compatible Lifts
Designet for bruk med NVIDIA DGX-2 og NVIDIA DGX A100-servere
WS-2XTM WIDE SHELF (Bigger)
The WS-2X™ Wide Shelf is a 21″-wide (53.3 cm) plate attachment that can provide even more shelf surface area to fully support servers with side-structural frames across their entire width. It supports up to 500 lbs (227 kg) at the center and 300 lbs (136 kg) at the extended side edge.
Compatible Lifts
WS-3XTM WIDE SHELF (Biggest)
The WS-3X™ Wide Shelf is a 30″-wide (76.2 cm) plate attachment with the most shelf surface area available to fully support servers with side-structural frames across their entire width. It supports up to 500 lbs (227 kg) at the center and 300 lbs (136 kg) at the extended side edge. The WS-3X™ is compatible with the SL-350X®, SL-500X®, SL-1000X®, SL-500FX™, and the SL-500FXL™ ServerLIFT® data center lifts.
Compatible Lifts
FE-3X™ Utvidet hylle
Utvidet rekkevidde og Deep Rack Server Support
Få utvidet rekkevidde og dyp rack-serverstøtte med FE-3X ™ utvidet hylle. Designet for bruk med SL-500FX ™ frontlasterheis, gir denne kombinasjonen stiv støtte for servere dypt inn i ethvert rack. Perfekt for produsenter og systemintegratorer.
The FE-3X plate is a “dual-purpose plate.” It can be used to get deeper into a rack (providing an additional 9″ into the rack), and it can also be used like the LE-500X to provide assistance for unboxing servers and other IT equipment. It comes with hooks and straps just like the LE-500X.
Compatible Lifts
Data Center Lift Accessories
Enhance your data center lift experience with practical accessories. We have more accessories coming, so keep an eye out for them.
Mobile Charge & Swap MCS-12X™
Take a fully charged battery to the lift. Put the dead battery on the cart and turn the (lazy-susan type) table that has the fully charged battery on it, and install that. Then take the cart with the dead battery to an outlet and plug it in to recharge the battery.
Compatible Lifts
Electrostatic Discharge (ESD) Wheels
ANSI/ESD 20.20 – Protection of Electrical and Electronic Parts, Assemblies, and Equipment (Excluding Electrically Initiated Explosive Devices)
LTK: Lift Tool Kit
All the tools you need to perform basic maintenance and repair of a ServerLIFT data center lift.
